10 Chapter 1
Bottom View
Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Battery release
latch Releases the battery for removal.
4 Hard disk bay-
Secondary Houses the computer's hard disk (secured with screws)
(only for certain models).
5 Subwoofer Emits low frequency sound output.
6 Hard disk bay-
Main Houses the computer's hard disk
(secured with screws).
7 Memory
compartment Houses the computer's main memory.
8 Ventilation slots
and cooling fan Enable the computer to stay cool, even after prolonged
use.
Note: Do not cover or obstruct the opening of the fan.
