Chapter 1 9
Right View
Rear View
Icon Item Description
1 USB 2.0 port Connects to USB 2.0 devices
(e.g., USB mouse, USB camera).
2 Optical drive Internal optical drive; accepts CDs or DVDs.
3 Optical disk access
indicator Lights up when the optical drive is active.
4 Optical drive eject
button Ejects the optical disk from the drive.
5 Emergency eject hole Ejects the optical drive tray when the computer is
turned off.
Note: Insert a paper clip to the emergency eject
hole to eject the optical drive tray when the
computer is off.
6 Modem
(RJ-11) port Connects to a phone line.
7 RF-in port Accepts input signals from digital TV-tuner devices.
(only for certain models)
8 Kensington lock slot Connects to a Kensington-compatible computer
security lock.
# Item Description
1 Ventilation slots Enable the computer to stay cool, even after prolonged use.
