LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Item
Screw
Color
Part No.
C
M2.5 x L6
Black
86.00E33.736
E
M2 x L3
Silver
86.9A522.3R0
LCD MODULE
LCD BEZEL
Cx6
LCD ASSEMBLY
LEFT LCD
BRACKET
Ex3
RIGHT LCD
BRACKET
Ex3
LCD FPC
CABLE
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
Cx5
VGA
CAMERA
