Aspire Digital 8730Z - Manual (Page 44)

34 Chapter 1
Wireless 802.11 b/g/n Aspire 8730/8730Z: Lan Intel WLAN 533AN_MMWG
Shirley Peak/Foxconn Wireless LAN Wireless LAN Ralink
RT2700E 1x2 BGN
Aspire 8530: Foxconn Wireless LAN Atheros AR5B91 1x2
BGN/Foxconn Wireless LAN Wireless LAN Ralink
RT2700E 1x2 BGN
6 in 1 Card Reader Realtek USB Card Reader
Audio Codec Realtek ALC888s Azalia
Keyboard
Item Specification
Keyboard controller NS PC97541V
Total number of keypads 105/106-key keyboard
Windows logo key Yes
Internal & external keyboard work
simultaneously Plug USB keyboard to the USB port directly: Yes
Battery
Item Specification
Vendor SONY/Sanyo
Battery Type Li-ion
Pack capacity 8 cell 4800mAh
Number of battery cell 8
Package configuration 4 cells in series, 2 series in parallel
LCD 18.4” inch
Item Specification
Vendor & model name CMO/Samsung
Screen Diagonal (mm) 18.4 inches
Display resolution (pixels) 18.4" Full HD 1920 x 1080/18.4" HD+ 1680 x 945
Pixel Pitch 0.204 x 0.204
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
Typical White Luminance (NIT)
also called Brightness
220
Luminance Uniformity 1.25 max.
Contrast Ratio 400 typical
Response Time msec 8
Nominal Input Voltage VDD +3.3V
Viewing Angle (degree)
Horizontal: Right/Left
Vertical: Upper/Lower
45/45
15/35
System Board Major Chips
Item Controller
