Machine overview
25 1. Introduction
11
Rear view
• This illustration may differ from your machine depending on your model. There are various types of machine.
• Some features and optional goods may not be available depending on model or country (see "Features by model" on page 7).
CLX-419x series/C186x series CLX-626x series
1 Waster toner container 4 Power receptacle 7
USB port
b 10
Extension telephone socket (EXT.)
c
2 Rear cover 5 Power-switch 8 Network port
3 Rear cover handle 6 5V output port for IEEE 1284B Port ab
a. This is an optional feature. CLX-626x series only.
b. The optional IEEE 1284B parallel connector can be used by plugging in both the USB port and the 5V output port.
9 Telephone line socket (LINE) c
c. CLX-419xFN/CLX-419xFW/C186xFW/CLX-626xFD/CLX-626xFR/CLX-626xFW only.
