Machine overview
23 1. Introduction
10
Front view
• This illustration may differ from your machine depending on your model.
There are various types of machine.
• Some features and optional goods may not be available depending on
model or country (see "Features by model" on page 7).
CLX-419x series/ C186x series/CLX-626xND/ CLX-626xFD
14
13 2 1
4
7
5
8
3
12
6
10
17
18
19
20
21
15
16
G
11
9
1 Automatic Document Feeder
(ADF) cover 12
Front cover handle
2 Automatic Document
Feeder(ADF) width guide 13
Scanner lid
3 Automatic Document
Feeder(ADF) input tray 14
Scanner glass
4 Automatic Document
Feeder(ADF) output tray 15 Paper width guides on a manual
feeder
5 Control panel 16 Manual feeder
6
Control board cover
17 Paper width guides on a multi-
purpose tray
a
a. CLX-626xND/ CLX-626xFD only.
7 Front cover 18
Multi-purpose support tray
a
8 Tray 1 19 Toner cartridge
9 USB memory port 20 Toner cartridge handle
10 Output tray 21 Intermediate Transfer Belt (ITB)
11
Document feeder output support
22
NFC tag
b
(Near Field
Communication)
b. C186xFW only.
