Appendix A. Wiring for Older HMP45C Probes

TABLE A-2. Connections for Differential Measurements for Old Wiring Configurations


Color


Description

CR10(X), CR510,

CR500

CR1000, CR3000

CR800, CR9000,

CR23X


21X, CR7

Yellow Temperature

Differential

Input

(H)

Differential Input (H)

Differential Input (H)

Jumper to

Purple

Signal Reference

Differential Input (L)

Differential Input (L)

Differential Input (L)

Blue

Relative Humidity

Differential Input (H)

Differential Input (H)

Differential Input (H)

Purple

Signal Reference

Differential Input (L)

Differential Input (L)

Differential Input (L)

Orange

Power Control

Control Port

Control Port

Control Port

Red

Power

12 V

12 V

12 V

Black Power

Ground

G

G

Clear Shield

G

This is a blank page.

A-2
