Model HMP45C Temperature and Relative Humidity Probe

BeginProg
Scan(1,Sec,1,0)

'HMP45C Temperature & Relative Humidity Sensor measurements AirTC and RH:

SW12

(1

)

Delay(0,150,mSec)
VoltDiff

(AirTC,1,mV2500,2,True,0,_60Hz,0.1,-40)

VoltDiff

(RH,1,mV2500,1,True,0,_60Hz,0.1,0)

SW12

(0)

If RH>100 And RH<108 Then RH=100

CallTable(Temp_RH)
NextScan
EndProg

CR10(X) Program using Differential Measurement Instructions Using SW12V on Datalogger

;Turn the HMP45C on.
;
01: Do (P86)
1: 41

Set Port 1 High

;Jumper wire from SW12V control to C1

;Orange wire (C1) if older wiring

;Green wire (C1) if using SW12V device

;For CR23X or CR5000 use 49 for SW12V internal

;control

port


;Pause 150 mSec before making measurements so the
;probe can stabilize on true readings.
;
02: Excitation with Delay (P22)
1: 1

Ex

Channel

2: 0

Delay W/Ex (units = 0.01 sec)

3: 15

Delay After Ex (units = 0.01 sec)

4: 0

mV

Excitation


;Measure the HMP45C temperature.
;
03: Volt (Diff) (P2)
1: 1

Reps

2: 5

2500 mV Slow Range

;CR510, CR500 (2500mv); CR23X (1000 mV);

21X, CR7 (5000 mV)

3: 2

DIFF

Channel

;Yellow wire (2H), jumper (2L to 1L)

4: 1

Loc [ T_C ]

5: .1

Mult

;See Table 5-1 for alternative multipliers

6: -40

Offset

;See Table 5-1 for alternative offsets

11
