Model HMP45C Temperature and Relative Humidity Probe

The temperature and relative humidity signals from the HMP45C can be
measured using a single-ended analog measurement or a differential analog
measurement.

Use a single-ended analog measurement when the HMP45C signal lead length
is less than 6.1 m (20 ft.) or if the probe will be turned on and off under
datalogger control between measurements. For lead lengths greater than 6.1 m
(20 ft.) or when the probe will be continuously powered, use a differential
analog measurement. For a discussion on errors caused by long lead lengths
see Section 6.

The HMP45C output scale is 0 to 1000 millivolts for the temperature range of
-40

°C to +60°C and for the relative humidity range of 0 to 100%. Tables 5-1

and 5-2 provide calibration information for temperature and relative humidity.

TABLE 5-1. Calibration for Temperature

Units

Multiplier

(degrees mV

-1

)

Offset

(degrees)

Celsius 0.1

-40

Fahrenheit 0.18

-40

TABLE 5-2. Calibration for Relative Humidity

Units

Multiplier

(% mV

-1

)

Offset

(%)

Percent 0.1

0

Fraction 0.001

0

TABLE 5-3. Wiring for Single-ended

Measurement Examples

Color Description CR1000

CR10(X)

Yellow

Temperature

SE 2 (1L)

SE 3 (2H)

Blue

Relative Humidity SE 1 (1H)

SE 4 (2L)

White Signal

Reference

AG

Jumper

from

SW12V Control

C1

Red Power SW12V

SW12

V

Black Power

Ground

AG

Clear Shield

G

7
