Model HMP45C Temperature and Relative Humidity Probe

Because of the inverse relationship between relative humidity and air
temperature, finding the mean relative humidity is meaningless. A more useful
quantity is the mean vapor pressure. The mean vapor pressure can be
computed on-line by the datalogger as shown in the following examples.

TABLE 7-1. Wiring for Vapor Pressure Examples

Color Description CR1000

CR10(X)

Yellow

Temperature

SE 2 (1L)

SE 3 (2H)

Blue

Relative Humidity SE 1 (1H)

SE 4 (2L)

White Signal

Reference

AG

Jumper

from

SW12V Control

C1

Red Power SW12V

SW12

V

Black Power

Ground

AG

Clear Shield

G

CR1000 Program that Computes Vapor Pressure and Saturation Vapor Pressure

'CR1000 program that calculates Vapor Pressure

Public AirTC
Public RH
Public RH_Frac, e_Sat, e_kPa

DataTable(Temp_RH,True,-1)
DataInterval(0,60,Min,0)
Average(1,AirTC,IEEE4,0)
Sample(1,RH,IEEE4)
Sample(1,e_kPa,IEEE4)
EndTable

BeginProg
Scan(1,Sec,1,0)

'HMP45C Temperature & Relative Humidity Sensor measurements AirTC and RH:

SW12

(1

)

Delay(0,150,mSec)
VoltSE(AirTC,1,mV2500,2,0,0,_60Hz,0.1,-40.0)
VoltSE(RH,1,mV2500,1,0,0,_60Hz,0.1,0)
SW12

(0)

If RH>100 And RH<108 Then RH=100

'Calculate

Vapor

Pressure

'Convert RH percent to RH Fraction

RH_Frac = RH * 0.01

'Calculate Saturation Vapor Pressure

13
