ROHM RZP / RZP-A 3-jaw centric gripper - Manual (Page 2)

Comparison: RZP; RZP-A
3-jaw centric grippers
___________________________________________________________________________
ID 1104572 Operating Manual RZP; RZP-A
Röhm GmbH, Dillingen Works Röhmstr. 6, 89407 Dillingen/Donau, GERMANY, Tel. (49)9071/508-0
Page 2 of 39
3-jaw centric grippers, pneumatically actuated
RZP
Functional principle
• Tried-and-tested T-slots for gripping under maximum load
•
Suitable for quick and efficient gripping
•
Centrical gripping of round and angular workpieces
• Universal use by using different clamping jaws
•
Optimum use in series production
• All sizes are available with two stroke lengths
•
Clamping force regulation by means of pressure change
• Constant clamping force at the same pressure, and therefore high clamping precision
•
Compact, ergonomic form
•
Purge port to prevent contamination
• Grippers can be installed on one gripper side
•
Position polling possible by means of inductive and magnetic sensors
• Compressed air port via screw connection or direct port
•
Gripping force lock for outer or inner gripping as extra type
• Base jaw / top jaw interface with centring sleeves
