Description of the RZP Centric Grippers
3-jaw centric grippers
ID 1104572 Operating Manual RZP; RZP-A
Röhm GmbH, Dillingen Works Röhmstr. 6, 89407 Dillingen/Donau, GERMANY, Tel. (49)9071/508-0
Page 17 of 39
Option: Resilient pressing star
RZP
A
A
Schnitt A-A
1
2
4
5
6
3
Item
Designation
Wear part
1 Pressing star
2 Thrust bolt
3 Countersunk-head screw DIN 7991
4 Compression spring
x
5 Shaft seal ring
x
6 Grub screw
