Description of the Parallel Gripper
Parallel Long Stroke Gripper RGP
Id.1140167 Operating Instructions RGP
Röhm-Tool GmbH, Röhmstr. 6, 89407 Dillingen/Donau, GERMANY, Tel. (49)9071/508-0
Page
3 of 14
Description Parallel Long Stroke Gripper RGP
Pos. Name
Consumable
1
BODY RGP
2
STEERING RACK RGP
3
INTERMEDIATE JAW RGP
4
PISTON DISC RGP
5
PISTON ROD RGP
6
SOCKET RGP
7
CARRIER RGP
8
COVER RGP
9
GEAR WHEEL RGP
10
GEAR WHEEL BEARING RGP
11
DAMPING RING RGP
12
WIPER BLADE RGP
13
SLIDING BLOCK RGP
14
HOLDER
15
CENTERING SLEEVE
16
CENTERING SLEEVE
20
FASTENING SCREW
21
FASTENING SCREW
22
FASTENING SCREW
23
FASTENING SCREW
24
FASTENING SCREW
25
FASTENING SCREW
26
FASTENING SCREW
28
FASTENING SCREW
30
SET SCREW DIN913
31
SET SCREW DIN913
32
SET SCREW DIN913
33
SET SCREW DIN915
35
HEX- NUT DIN934
36
PLUG SCREW EO2
38
CYL-PIN D DIN7979
39
CYL-PIN D DIN7979
40
O-RING
x
41
O-RING
x
42
O-RING
x
43
O-RING
x
45
SEALING RING
x
47
PISTON SEAL
x
48
ROD SEAL
x
49
PISTON GUIDE RING SLYDRING
x
50
PRESSURE SPRING
x
51
PRESSURE SPRING
x
55
FILTER DISC
56
ROUND MAGNET
