Chapter 3. Operation
61200263L1-1.2A ATLAS Router User Manual 3-7
Interfaces
The Interfaces Menu (see Figure 3-7) configures and monitors all interfaces con-
nected to the ATLAS router. These include the Ethernet and frame relay DLCIs
connected in the Packet Manager/ Packet Cncts.
Figure 3-7. Interfaces Menu
Network Name
Read Security: 5
Displays the name of the interface connected to the ATLAS router. The options are
listed below:
Address
Write Security: 3; Read Security: 5
Defines the individual interface IP address. If this field is left as 0.0.0.0, it is
treated as an unnumbered interface.
Subnet Mask
Write Security: 3;Read Security: 5
Defines the subnet mask applied to the address defined for this link. If the subnet
mask is unnumbered, leave as 0.0.0.0.
EN0 IP ATLAS Ethernet port
Endpoint Name (DLCI #)
