40
7 Ordering
7.1 Part Numbering Scheme
Table 53: Part Numbering Scheme
GLK -24064 -16 -1U -USB -FGW -E
1 2 3 4 5 6 7 8
7.2 Options
Table 54: Display Options
# Designator Options
1 Product Type GLK: Graphic Liquid Crystal Display with Keypad Input
2 Display Size 24064: 240 pixel columns by 64 rows
3 Keypad Size 16: 16 key maximum
4 Form Factor 1U: Designed to 1U, or PC bay insert, dimensions
5 Protocol
NP: Standard Model
-USB: USB Only Model
6 Colour
FGW: Grey Text with White Background
WB: White Test with Blue Background
* TCI: Tricolour Text with Black Background
7 Voltage
NP: Standard Voltage
-LV: Low Voltage
-V: Wide Voltage
-VPT: Wide Voltage with Efficient Switching Power Supply
8 Temperature
NP: Standard
-E: Extended Temperature
*Note: Tricolour options are available for the Standard, Non-USB model only.
