21
5.4 Bitmaps
4.1 Upload a
Bitmap File Dec
Hex
ASCII 254 94
FE 5E
■ ^
ID Size Data
ID Size Data
ID Size Data
Upload a bitmap to a graphic display. To create a bitmap see the Bitmap File Creation section, for upload protocol
see the File Upload Protocol or XModem Upload Protocol entries.
ID 1 byte, unique bitmap identification number, must be less than 128
Size 2 bytes, width and height of the bitmap
Data variable length, bitmap file data, see Bitmap File Creation example
4.2 Draw a Bitmap
from Memory Dec
Hex
ASCII 254 98
FE 62
■ b
ID X Position Y Position
ID X Position Y Position
ID X Position Y Position
Draw a previously uploaded bitmap from memory. Top left corner must be specified for drawing.
ID 1 byte, unique bitmap identification number
X Position 1 byte, leftmost coordinate of bitmap
Y Position 1 byte, topmost coordinate of bitmap
4.3 Draw a Bitmap
Directly Dec
Hex
ASCII 254 100
FE 64
■ d
X Position Y Position Width Height Data
X Position Y Position Width Height Data
X Position Y Position Width Height Data
Draw a bitmap directly to the graphic display without saving to memory.
X Position 1 byte, leftmost coordinate of bitmap
Y Position 1 byte, topmost coordinate of bitmap
Width 1 byte, width of bitmap
Height 1 byte, height of bitmap
Data bitmap dependent, see Bitmap File Creation example
