36
Table 41: Drawing Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Set Drawing Colour 99 63 c Colour None Remember On
Draw Pixel 112 70 p X, Y None Never
Draw a Line 108 6C l X1, Y1, X2, Y2 None Never
Continue a Line 101 65 e X, Y None Never
Draw a Rectangle 114 72 r Colour, X1, Y1, X2, Y2 None Never
Draw a Solid Rectangle 120 78 x Colour, X1, Y1, X2, Y2 None Never
Initialize a Bar Graph 103 67 g ID, Type, X1, Y1, X2, Y2 None Remember On
Draw a Bar Graph 105 69 i ID, Value None Never
Initialize a Strip Chart 106 6A j ID, X1, Y1, X2, Y2 None Remember On
Shift a Strip Chart 107 6B k DirectionID None Never
Table 42: General Purpose Output Command Summary
Name Dec Hex ASCII Parameters Response Remembered
General Purpose Output Off 86 56 V Number None Never
General Purpose Output On 87 57 W Number None Never
Set Start Up GPO State 195 C3 ├ Number, State None Always
Table 43: Keypad Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Auto Transmit Key Presses On 65 41 A None None Remember On
Auto Transmit Key Presses Off 79 4F O None None Remember On
Poll Key Press 38 26 & None KeyPress Never
Clear Key Buffer 69 45 E None None Never
Set Debounce Time 85 55 U Time None Remember On
Set Auto Repeat Mode 126 7E ~ Mode None Remember On
Auto Repeat Mode Off 96 60 ` None None Remember On
Assign Keypad Codes 213 D5 ╒ KeyUp [16], KeyDown [16] None Always
Table 44: Display Functions Command Summary
Name Dec Hex ASCII Parameters Response Remembered
Display On 66 42 B Minutes None Remember On
Display Off 70 46 F None None Remember On
Set Brightness 153 99 Ö Brightness None Remember On
Set and Save Brightness 152 98 ÿ Brightness None Always
Set Backlight Colour 130 82 ‘ Red, Green, Blue None Remember On
Set Contrast 80 50 P Contrast None Remember On
Set and Save Contrast 145 91 æ Contrast None Always
