38
6.2 Environmental Specifications
Table 48: Environmental Limits
Standard Extended (-E)
Operating Temperature 0°C to +50°C -10°C to +60°C
Storage Temperature -10°C to +60°C -20°C to +70°C
Operating Relative Humidity Maximum 90% non-condensing
6.3 Electrical Tolerances
Current Consumption
Table 49: Current Consumption
Board
+
Backlight
+
GPOs
45mA 75 to 205 mA 20mA each maximum
Table 50: Backlight Current Draw
GW & WB TC & TCI
75mA 205mA
Input Voltage Specifications
Table 51: Voltage Specifications
Low Voltage (-LV) Standard Wide Voltage (-V) Extended Wide Voltage (-VPT)
3.3V 4.75-5.25V 9.0-15.0V 9.0-35.0V
6.4 Optical Characteristics
Table 52: Display Optics
Module Size 112.00 x 38.00 x 28.9 mm
Viewing Area 98.0 x 28.4 mm
Active Area 93.57 x 24.93 mm
Pixel Size 0.36 x 0.36 mm
Pixel Pitch 0.39 x 0.39 mm
Viewing Direction 12 O’clock
Viewing Angle -30 to +30 °
Contrast Ratio 3
Backlight Half-Life 20,000 Hours
