17
5.2 Text
2.1 Auto Scroll
On Dec
Hex
ASCII 254 81
FE 51
■ Q
The entire contents of screen are shifted up one line when the end of the screen is reached. Display default is on.
2.2 Auto Scroll
Off Dec
Hex
ASCII 254 82
FE 52
■ R
New text is written over the top line when the end of the screen is reached. Display default is Auto Scroll on.
2.3 Clear
Screen Dec
Hex
ASCII 254 88
FE 58
■ X
Clears the contents of the screen.
2.4 Set Cursor
Position Dec
Hex
ASCII 254 71
FE 47
■ G
Column Row
Column Row
Column Row
Sets the cursor to a specific cursor position where the next transmitted character is printed.
Column 1 byte, value between 1 and number of character columns
Row 1 byte, value between 1 and number of character rows
2.5 Set Cursor
Coordinate Dec
Hex
ASCII 254 121
FE 79
■ y
X Position Y Position
X Position Y Position
X Position Y Position
Sets the cursor to an exact pixel position where the next transmitted character is printed.
X Position 1 byte, value between 1 and screen width, represents leftmost character position
Y Position 1 byte, value between 1 and screen height, represents topmost character position
2.6 Go Home Dec
Hex
ASCII 254 72
FE 48
■ H
Returns the cursor to the top left of the screen.
