The character data is a binary graphical representation of each glyph in a font. Each character is drawn
on a grid containing as many rows as the height specified in the header and as many columns as the
width specified in the character table. Cells are drawn by writing a one in their location and cleared by
setting a value of zero. Starting at the top left, moving right, then down, eight of these cells form a
character data byte. When all cells are accounted for, zeroes may be added to the last byte to complete
it. A sample of an ‘h’ glyph is shown above. The data for the ‘i’ and ‘j’ characters will follow to complete
the custom font file displayed below.
Table 20: Example Font File
Header 5 7 72 74
Character Table
h 0 13 5
i 0 18 3
j 0 21 4
Character Data
h 132 45 152 198 32
i 67 36 184
j 16 49 25 96
