background image

Command

Syntax

Default

Notes

Upload bitmap

FE ^E [ref] [size] [data]

254 94[ref] [size] [data]

254 ’^’ [ref] [size] [data]

n/a

Uploads a bitmap

to the memory of

the display.

Upload font

FE 24 [ref] [size] [data]

254 36 [ref] [size] [data]

254 ’$’ [ref] [size] [data]

n/a

Uploads a font to

the memory of the

display.

9.7 Miscellaneous Commands

Table 17: Miscellaneous Commands

Command

Syntax

Default

Notes

Clear display

FE 58

254 88

254 ’X’

n/a

Clears screen of

text and graphics,

places text cursor

at top left.

Set contrast

FE 50 [contrast] 254 80

[contrast] 254 ’P’ [con-

trast]

128

Sets display con-

trast.

Compen-

sates for viewing

angle.

Contrast

is a value between

0 and 255 (hex 0

to FF). Larger =

darker.

Set contrast and save

FE 91 [contrast] 254 145

[contrast]

128

Same as "Set con-

trast" but saves

[contrast] as de-

fault.

Backlight on

FE 42 [minutes]

254 66 [minutes] 254 ’B’

[minutes]

on

Backlight

will

stay on for [min-

utes]. If [minutes]

=

0 backlight

will

stay

on

permanently.

Backlight off

FE 46

254 70

254 ’F’

on

Turns off back-

light.

Set backlight brightness

FE 99

254 153

On (Full Inten-

sity)

Changes

the

intensity of the

backlight.

Matrix Orbital

GLK12232-25-SM

34
