Table 8: Speed Settings
Speed Value Speed
20 Hex 9600 baud
0F Hex 19200 baud
95 Hex 57600 baud
03 Hex 76800 baud
8A Hex 115000 baud
8.1.13 Set Serial Number (254 52 [byte1] [byte2]
Modules may be delivered with the serial number blank. In this case the user may set the desired 2 byte
serial number using this one time only command.
Upon the execution of this command, the module will echo these two bytes back over the RS-232 inter-
face. The serial number may be set only once. Any future attempt to execute this command will result in no
change and the module will return to the originally set serial number.
8.1.14 Read Serial Number (254 53)
This command will return, over the RS-232 interface, the 2-byte serial number of the module as it was
previously stored.
8.1.15 Read Version Number (254 54)
This command will return the firmware version number of the display. Version number will be a 1-byte
hex value.
9 Appendix: Command Summary
9.1 General
The operation of the display is controlled by a simple and consistent command set. Commands control;
• Text display
• Graphics display
• Keypad interface
• The display file system
• Miscellaneous operating parameters
This chapter includes summary tables of all commands.
Matrix Orbital GLK12232-25-SM 29
