MAN4005-04-EN GPRS / GSM MODEM Configuration PAGE 7
•
If an SMS transmission needs to be carried out when the GSM connection is active then additional Data
Transmission Settings need to be entered for servicing SMS. If SMS needs to be serviced when a GSM
connection is active, select Enable SMS Configuration. This will enable
Data Transmission Settings .
Select the checkbox and set the idle time after which SMS should be serviced i.e. if 10 secs is configured
in this field, when the connection is idle (status 6) for 10 secs, SMS send/received (Status 5) would be
serviced. If the checkbox is not selected, SMS will not be serviced.
•
Additional ladder programming must be written to answer or to make GSM data call using communication
operation ladder blocks. Use of Communication blocks for
GSM/GPRS connectivity is detailed in section 4.
1.1.2 Connectivity with Cscape
•
On the device, Change the default programming port to GSMGPRS from the system menu, serial port
option, i.e. OCS ‘system menu -> Set Serial Ports -> Dflt Pgm Port ->GSM’ for MJ1.
Page 7 of 62 ECN # 956
