PAGE 40 GPRS / GSM MODEM Configuration MAN4005-04-EN
6 GPRS / GSM Modem Specifications
HE-GSM04 SPECIFICATIONS
Antenna Interface Female SMA.
Frequency bands EGSM 900, DCS 1800, and PCS 1900, GSM 850 capability.
GSM/GPRS features
supported
Provides for all GSM/GPRS authentication, encryption, and frequency hopping algorithms. GPRS Coding Schemes CS1-CS4
supported. Multi-Slot Class 10 (4RX/2TX, Max 5 Slots).
Regulatory
Agency approvals
GCF Type Approval
PTCRB Type Approval
FCC Certification (Part 24)
RTTE
CE (European Community Certification)
IC (Industry Canada) Approval
GSM/GPRS
Functionality
Mobile-originated and mobile-terminated SMS messages: up to 140 bytes or up to 160 GSM 7-bit ASCII characters.
Reception of Cell Broadcast Message
SMS Receipt acknowledgement
Circuit Switched Data (Transparent & Non-transparent up to 9.6 Kbps)
Voice (EFR, FR, HR)
Supports Unstructured Supplementary Service Data (USSD)
Multi-Slot Class 10 Supported (4Rx/2TX), (5 Slot Max)
PBCCH/PCCCH Supported.
SIM 3 V Mini-Subscriber Identity Module (SIM) compatible
Size (L x W) 82.3 mm x 34.6 mm x 3.1 mm
Weight Less than 80 grams
Operating & Storage
temperature
0°C to +60°C (Operating)
-10°C to +85°C (Storage)
Relative humidity 5 - 95%
Air pressure (altitude) 70 kPa to 106 kPa (-400 m to 3000 m)
Frequency Power Class Transmit Power
1900 MHz
1800 MHz
GSM Power Class 1
1-W conducted power maximum (30 dBm +/- 2 dB), measured at the
antenna port Transmit Power
850 MHz
900 MHz
GSM Power Class 4
2-W conducted power maximum (33 dBm +/- 2 dB),
measured at the antenna port
Frequency Sensitivity Mode
1900 MHz
1800 MHz
-106 dBm (typical) GPRS Coding Scheme 1 (CS1)
Receive Power
850 MHz
900 MHz
-106 dBm (typical)
GPRS Coding Scheme 1 (CS1)
