Cleanup (cup mode)
8. Clean all parts thoroughly with the brush provided
using a solution appropriate to the type of material you
sprayed.
9. IMPORTanT: Make sure to completely remove all
material from the inside of the piston chamber by
scrubbing with the brush. Even a small amount of
material can dry like glue and keep the piston from
moving, causing damage to the sprayer.
10. IMPORTanT: Make sure to keep the vent hole (a) on
the pump housing clean and unblocked or a vacuum
can build up in the container and cause damage to the
sprayer. a toothpick or straightened paper clip can
be used to clean it.
11. Latex materials only - Thread the cleaner nozzle onto a
garden hose.
12. Latex materials only - Insert nozzle into the end of the
suction tube and place into a waste container.
Turn on the water and flush the suction tube until clean.
13. Oil-based materials only - Using the cleaning brush and
mineral spirits, clean out the inside of the suction tube.
14. Lubricate the O-rings as shown with the included
lubricant.
Reassemble the filter assembly.
8
9
(a)
10
12
(a)
(b)
14
11
13
