MagTek MICRImage - Manual (Page 41)

Section 4. Image Specific Commands
33
The MICRImage responds with a status string formatted as follows:
abc,size,fn
where
a = image status (N-None, S-Scanned, L-Scanned/Locked)
b = compression(N-None, G-compressed)
c = image type (0-None, 1,2,4,8 bit)
size = image size in # of bytes
fn = image filename (noname- name not determined yet)
Example responses:
NN0,0,noname
- No image in memory
SG1,5333,noname - Scanned B/W image (5333 bytes) in memory
LG1,5333,file7.tif - Same image after being sent (image is now locked)
One of the following optional parameters may be used:
F Returns the status information as described above for the next file to be transmitted by the
SF command.
D Returns the length and height in pixels of the current image.
K Kills (cancels) the current image. This is done automatically whenever an image is saved
in internal storage or a new document is scanned.
Examples: IS F may return
LG1,9726,MYIMAGE.TIF
IS D may return
1208,540
IS K returns NN0,0,noname
AI – APPEND IMAGE COMMAND
The AI command can be used to append additional documents to the same bi-tonal compressed file. The
user is not prompted for the next scan. This command may be canceled by typing cntl-X. The following
optional parameters may be used:
