MICRImage Check Reader
24
For example, to setup a color pattern where the LED illuminates green-red-green-red, the byte value
would be “01100110” (decimal 102). The decimal value of this byte is used with the LE command. In this
example, the LE command is executed as follows:
LE 102
Table 3-1 lists common color patterns with their values and descriptions:
Table 3-1. LED Control
Color Pattern Color Value
(Decimal)
Description
Off/Off/Off/Off 0 LED Off
Green/Green/Green/Green 85 Steady Green
Red/Red/Red/Red/ 170 Steady Red
Amber/Amber/Amber/Amber 255 Steady Amber
Green/Green/Off/Off 80 Blink Green Slow
Red/Red/Off/Off 160 Blink Red Slow
Amber/Amber/Off/Off 240 Blink Amber Slow
Red/Red/Green/Green 165 Blink Red/Green Slow
Green/Off/Green/Off 68 Blink Green Fast
Red/Off/Red/Off 136 Blink Red Fast
Amber/Off/Amber/Off 204 Blink Amber Fast
Red/Green/Red/Green 153 Blink Red/Green Fast
Red/Green/Off/Off 144 Fast Red/Green Off
Green/Green/Green/Red 86 Green + Fast Red
Red/Red/Red/Green 169 Red + Fast Green
Once the color pattern is defined, the pattern is repeated for a default interval of 3 seconds. A different
time period can be specified using the LE command and providing a new value in seconds, up to 65. For
example, to setup a 5 second interval for the color pattern above, the LE command is executed as follows:
LE 85,5
Note
The total time for each color pattern is 0.4 seconds (i.e. each segment lasts 0.1 seconds).
DM – DISABLE MICRIMAGE COMMAND
This command disables the document reading function and turns off the LED. Communications are not
affected, and Insta-change checks may still be scanned, but the MICR line will not be sent.
DM Insta-change checks only may be scanned
DMX No scans at all
