If Multiple Message: ‘M’[TK1]‘M’[TK2]‘M’[TK3]
If Single Message: ‘M’[TK1] [TK2] [TK3]
Extended Replies
There are a number of commands in the standard MICR command set that do not provide any
response when the operation is completed or with a simple '? when an error occurs. By
setting this option, commands that normally provide no response will return 'OK' if the
command executes successfully. For commands that respond with a '?' to report an error,
the extended reply is '?xxx' where xxx is a three-digit error code. See Appendix D for a
complete listing of the error codes.
‘No MICR’ Response
For applications where both MICR and non-MICR encoded documents will be scanned, setting
this option will provide a 'No MICR' response when no MICR characters are detected.
SWD COMMAND – AUXILIARY PORT PARAMETERS
The SWD command, shown in Table 2-6, controls the communication parameters for the RS-232
Auxiliary Port.
Table 2-6. SWD Command – Auxiliary Port Parameters
BITS FUNCTION
7 6 5 4 3 2 1 0
0 0 0 Baud Rate: 57600
0 0 1 Baud Rate: 38400
0 1 0 Baud Rate: 115200
0 1 1 Baud Rate: 1200
1 0 0 Baud Rate 2400
1 0 1 Baud Rate: 4800
1 1 0 Baud Rate: 9600
1 1 1 Baud Rate: 19200
0 0 0 Data, Stop Bits, Parity: 8, 1, None
1 0 0 Data, Stop Bits, Parity: 8, 2, None
0 0 1 Data, Stop Bits, Parity: 8, 1, Even
1 0 1 Data, Stop Bits, Parity: 8, 1, Odd
0 1 0 Data, Stop Bits, Parity: 7, 1, Even
1 1 0 Data, Stop Bits, Parity: 7, 2, Even
0 1 1 Data, Stop Bits, Parity: 7, 1, Odd
1 1 1 Data, Stop Bits, Parity: 7, 2, Odd
0 CTS/DSR: Use
1 CTS/DSR: Ignore
0 Intercharacter Delay: No
1 Intercharacter Delay: Yes
