Appendix B. Bezel Configuration and Mounting
27
INTERNATIONAL METAL BEZEL MOUNTING
The International Metal Bezel (P/N 21161204) is shown and described in Figure B-3. The Bezel
also requires the front flanges for attaching the Bezel to the unit (see Figure B-1). Four screws
are inserted into the front flange slots to retain the unit to the bezel. These screws are thread
cutting and may be either Phillips head or T10 Torx
®
.
Figure B-3 also shows the orientation and dimensions of the bezel and recommended dimensions
for the panel opening. Four screws that mount the Bezel to the panel are also M3.5. The length
of the screws depends on the panel thickness, washers, and spacers used in mounting the panel.
Compatibility
The Metal Bezel is not compatible with some units. The units compatible with the Metal Bezel
are 1) front mount and 2) front and side mount together (M1 and M3). The units not compatible
with the Metal Bezel are 1) side mount and 2) no mount (M2 and M4). Table B1 lists examples
of units compatible with the Metal Bezel. Table B2 lists examples of units not compatible with
the Metal Bezel.
Table B1. Examples of Configurations Compatible with the Metal Bezel
Part Number Model Mounting Description
21165048 IntelliStripe 65 M3 – Front and Side Mounted I65 with flanges and bosses
21165051 IntelliStripe 65 M3 – Front and Side Mounted I65 with flanges and bosses
21165052 IntelliStripe 65 M3 – Front and Side Mounted I65 with flanges and bosses
21165053 IntelliStripe 65 M3 – Front and Side Mounted I65 with flanges and bosses
21165059 IntelliStripe 65 M3 – Front and Side Mounted I65 with flanges and bosses
Table B2. Examples of Configurations Not Compatible with the Metal Bezel
Part Number Model Mounting Description
21165042 IntelliStripe 65 M2 – Side Mounted I65 with bosses only
21165043 IntelliStripe 65 M2 – Side Mounted I65 with bosses only
