Section 1. Features and Specifications
7
Table 1-1. Specifications
DATA FORMAT SPECIFICATION
Reader Configuration
Mag-Stripe Functions
Track 1,2,3 only
Smartcard Functions
Data Format Specification*
ISO/AAMVA/ JIS formats
ISO 7810, 7811, JIS x 6302 Type 2
ISO 7816 T=0 and T=1 protocols, many popular memory cards
EMVCo Level 1 Approval
* ISO (International Standards Organization), AAMVA, (American Association of Motor Vehicle
Administrators), JIS (Japanese Industrial Standard)
OPERATIONAL
Card Speed 3 IPS (7,62 cm/sec) to 50 IPS (127, cm/sec)
Recording Method Two-frequency coherent phase (F2F)
MTBF Head: 1,000,000 passes (500,000 Insertion Cycles)
SC contacts: 1,000,000 insertions
ELECTRICAL
Input Voltage
Current
12.0VDC
± 5%
500mA max, (1A with contactless smartcard option)
50mA idle, (300mA with contactless smartcard option)
MECHANICAL
Chassis Mounting Options
Front Flange See Section 2, Figure 2-1
Side Mounting Studs See Section 2, Figure 2-2
Side Mounting Holes See Section 2, Figure 2-2
Dimensions (Core Chassis)
Overall Length
Mounting Depth
Height
Width
4.70” (119,4mm)
3.80” (96,5mm) when mounted with front flanges
1.40” (35,6mm)
2.60” (66,0mm) without mounting bosses or flanges
Weight 5.02oz (142.2gr)
ENVIRONMENTAL
Temperature
Operating
Storage
-4
o
F to 122
o
F (-20
o
C to 50
o
C) (without contactless smartcard option)
-4
o
F to 122
o
F (-20
o
C to 50
o
C) (with contactless smartcard option)
-4
o
F to 158
o
F (-20
o
C to 70
o
C)
Humidity
Operating
Storage
10% to 90% noncondensing
10% to 90% noncondensing
Altitude
Operating
Storage
0-10,000 ft. (0-3,048 m.)
0-50,000 ft. (0-15,240 m.)
