Appendix A. Options
23
GATE OPTION
The location and parts of the Gate Assembly are shown in Figure A-3.
Figure A-3. Gate Assembly
Gate Latch,
Head Side
Gate. Bottom Edge
Contoured to Stay Clear
of Card Embossing
Gate Interlock Area.
Gate Locks into Guide
Spring
Gate Return
Spring
