APPENDIX A. OPTIONS
CARD LATCH OPTION
The location and parts of the Card Latch Assembly are shown in Figure A-1.
Figure A-1. Card Latch Assembly
Actuator
Motor
Spring
Latch
Retainer
Latch
Finger
Actuator Link
