1 Required Tools, Materials, and Documents
1.1 Required Tools
Part Number Quantity Description
33011008 1 ea. ASM TOOL KIT,FIELD SERVICE,EC2000
67800019 or equiv. 1 ea. Small USB keyboard with touchpad mouse
N/A 1 ea. Small diagonal side cutters
N/A 1 ea. USB thumb drive with required software and documentation
1.2 Suggested Tools
Part Number Quantity Description
N/A 1 ea. Laptop with available Ethernet port
22350302 or equiv. 1 ea. 10 ft. Ethernet cable (COM ETHERNET CAT5E BLK 10')
N/A 1 ea. Flashlight
1.3 Required Materials
Part Number Quantity Description
97200153 1 ea. ASM KIT,PREVENTIVE MAINTENANCE,EC2000
1.4 Suggested Materials
Part Number Quantity Description
33011009 1 ea. ASM KIT,STARTER,SPARE,FIELD SERVICE,EC2000
93400047 1 ea. PRI RIBBON, COLOR YMCKOK EV (R3314)
33070896 1 ea. ASM RIBBON ASSY,TIP FOIL,SILVER
33070621 1 ea. AAY ASSY,INDENT CARTRIDGE
1.5 Required Software and Documents
MagTek recommends loading the following required software and documents on the USB thumb drive or
service laptop before visiting the customer site.
Part Number Quantity Description
99875600 1 ea. MNL USER INSTALL & OPERATION MANUAL,EC2000
99875607 1 ea. MNL HARDWARE SERVICE MANUAL,EC2000
99875651 1 ea. REF PROCEDURE,PREVENTIVE MAINTENANCE,EC2000
99875646 1 ea. REF CHECKLIST,PREVENTIVE MAINTENANCE,EC2000
N/A 1 ea. Passwords and factory defaults for the device being serviced
