8 Technical specifications
Power supply:
100 - 240 V~ 47/63 Hz
Power consumption:
15 W
Dimensions:
Rack 19” 1U
Net weight (excluding power supply):
2 Kg
Finish:
box in iron painted with epoxy powder
Video:
8/16 inputs - 1 Vpp - 75 Ohm terminated or high impedance
4 outputs - 1 Vpp - 75 Ohm loaded
Band width:
> 6 Mhz
Lower cut off frequency (-3dB)
9 Hz
Signal/noise ration (S/N) :
> 48 dB @ 5.5MHz
Operating temperature:
0 – 45°C
RS485:
4 lines keyboard – 1 line aux
RS232:
1 line
Relay contact:
50 V~ 0.3 A
Conformity:
EN50130-4 - EN50081-1 - EN60950 -
EN55022 Class B - FCC Part. 15 Class B
