Page 9 MNVCSM84A_0408
Dip switch
1
2 3 4 Protocol and baud rate Connected keyboards
OFF
OFF
OFF
OFF OFF
OFF
OFF
OFF OFF
OFF
ON
ON OFF
ON
OFF
ON Macro, 38400 baud (*)
Macro, 19200 baud
Macro, 9600 baud
Macro, 1200 baud New series keyboards:
DCJ, DCK, DCTEL, DCBD, DCT, DCIR
OFF
OFF ON
ON OFF
OFF OFF
ON Linxs, 9600 baud
Linxs, 1200 baud Linxs series keyboards:
LXRPK12, LXRPK23, LXRPRC36
OFF
OFF ON
ON ON
ON OFF
ON Videotec switchers, 9600 baud
Videotec switchers, 1200 baud Previous series keyboards:
SWC4, SWC8, DCMT8 with interface
ON
ON OFF
OFF OFF
OFF OFF
ON Videotec OSM, 9600 baud
Videotec OSM, 1200 baud Previous series keyboards:
DCS2, KEYPLUS, SWC16 with interface
ON OFF ON OFF Videotec SW328, 9600 baud Previous series keyboard: DCS3
ON
ON
ON
ON
ON OFF
ON
ON
ON
ON ON
OFF
OFF
ON
ON ON
OFF
ON
OFF
ON
Invalid configurations
-
(*)Default configuration
3.4.3 Inserting th e load on the AUX line
To insert/disconnect the 120 Ohm load on the RS485 AUX line, position jumper JP11 as shown in the diagram:
Jumper JP11 with load connected (position A)
Jumper JP11 with load disconnected (position B)
3.4.4 Setting 75 O hm video input termination
It’s possible to remove the 75 Ohm video input termination putting the corresponding jumper into position B.
Example: input 1-2-3 without load
