Videotec DTMRX2 User Manual
Page 35

Page 9
MNVCDTMRX2_0351
Note on terminal J5
Terminal J5 has a double row of
connectors. The screen printing
regarding the top row of connectors
is that nearest to the related terminal
(for example, NEUTRAL refers to
the upper terminal) while the screen
printing regarding the bottom row of
connectors is that further away (for
example COM refers to the lower
terminal). To insert the connecting
cables in the terminal board J5 use
a flat screwdriver in the appropriate
slots as shown in Figure 1.
Fig. 1
Screwdriver hole for
upper terminal
Screwdriver hole for
lower terminal
Upper terminal
Lower terminal
