5.3 Configuration DIP switches and Jumpers
In the following diagram identify the configuration DIP switches and Jumpers:
Trimmer TR1 for
adjusting lens voltage
BNC J1 and J2
for coaxial
reception
Jumper JP4
Jumper JP3
Connector J4
Screen printing for
top row terminals
Screen printing for
bottom row terminals
Terminals for
receiver power supply
