Pag. 3 MNPTH3553803
Identification data
On PTH355P pan & tilt motor there are two plates complying with EC specifications.
The first plate includes:
x Model identification code (Extended bar code 3/9 )
x Mains voltage (Volt)
x Frequency
(Hertz)
x Power consumption (Watt)
The second plate shows the model serial number (Extended bar code 3/9)
When installing the appliance, check that the power supply specifications of the pan & tilt motor correspond to those
required. The use of improper appliances may seriously compromise the safety of the personnel and the installation.
Description of PTH355P pan & tilt motor
PTH355P unit is a vertical and horizontal pan & tilt motor, expressly projected for outdoor installations.
The PRESET is delivered as standard.
Features
x Horizontal movement (Pan): from 0 to 345°. Speed: 30° per second
x Vertical movement (Tilt): from 0 to 360°. Speed: 18° per second
x Construction in corrosion-proof die-cast aluminium
x Completely sealed closing for indoor/outdoor operation
x Operating temperature from -20°C to +50°C (from -4°F to 122°F)
x PTH355P power supply: 24V =
x PRESET
Appliances compatible with PTH355P
The working of pan & Tilt motors ist guarrated only if connected to:
x DTRXDC control receiver: digital receiver, controlled by a microprocessor, for remote control of a variable speed
Pan & Tilt (PTH355P) and a motor-driven zoom lens. The connection to the control unit can be carried out in
RS232 or in RS485 (in this case, the connection distance can reach 1200m). This digital receiver is controlled by
the DCS3 keyboard and it is possible to recall up to 14 Pan & Tilt and optics preset positions with 4 local alarms.
Two auxiliary control relays are available for controlling, for instance, the switching on and off of a IR illuminator,
through a power contact. A IP65 weatherproof box ensures protection against all weather conditions.
6 PG11 cable glands make connection easier.
