EN - English - I

nstruc

tions manual

6

7 Maintaining and cleaning

7.1 Fuses replacement

Operation valid for pump with 5m (16ft) or

11m (36ft) delivery.

If the fuse needs to be replaced the one already

installed has the following characteristics:
Model Number: FUS4ATUL
Brand: OMEGA
Models: GT520240
Alternatively, use a T 4A L type fuse.

8 Disposal of waste
materials

This symbol mark and recycle system

are applied only to EU countries and not

applied to the countries in the other area of

the world.

Your product is designed and manufactured with

high quality materials and components which can be

recycled and reused.
This symbol means that electrical and electronic

equipment, at their end-of-life, should be disposed of

separately from your household waste.
Please dispose of this equipment at your local

Community waste collection or Recycling centre.
In the European Union there are separate collection

systems for used electrical and electronic products.

9 Technical data

WASHER PUMP AND TANk OF 5l (1.3GAl),

DElIVERy HEAD 5M (16FT)
Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 217x272x254mm
Reservoir capacity: 5l (1.3gal)
Delivery head: max 5m (16ft)
Tube length: 5m (16ft)
Power supply: IN 230Vac/120Vac/24Vac
Consumption: 18W max
Operating temperature: 60°C
Weatherproof standard: IP56

WASHER PUMP AND TANk OF 23l (6GAl),

DElIVERy HEAD 5M (16FT)
Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 301x410x348mm

(11.8x16.1x13.7in)
Reservoir capacity: 23l (6gal)
Delivery head: max 5m (16ft)
Tube length: 5m (16ft)
Power supply: IN 230Vac/120Vac/24Vac
Consumption: 18W max
Operating temperature: 60°C
Weatherproof standard: IP56
WASHER PUMP AND TANk OF 23l (6GAl),

DElIVERy HEAD 11M (36FT)
Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 301x410x348mm

(11.8x16.1x13.7in)
Reservoir capacity: 23l (6gal)
Delivery head: max 11m (36ft)
Tube length: 11m (36ft)
Power supply: IN 230Vac/120Vac/24Vac
Consumption: 60W max
Operating temperature: 60°C
Weatherproof standard: IP56
WASHER PUMP AND TANk OF 23l (6GAl),

DElIVERy HEAD 30M (98FT)
Polyethylene tank, stainless steel cage
Dimensions (WxHxL): 301x635x269mm

(11.8x25x10.6in)
Reservoir capacity: 23l (6gal)
Delivery head: max 30m (98ft)
Tube length: 30m (98ft)
Power supply: IN 230Vac/120Vac
Consumption: 450W max
Operating temperature: 60°C
Weatherproof standard: IP45
