Instruc
tions manual - English - EN
3
6.1 Installation
6.1.1 Installing the pump tank
If using the pump at temperatures below
3°C (37.4°F) add some antifreeze liquid to
the water.
The antifreeze liquid will cause irreparable
damage to the germanium glasses. For
pan & tilts fitted with germanium glasses,
do not use antifreeze liquid but add ethyl
alcohol in 20% solution.
Attach the metal cage (01) firmly to a wall using the
holes provided for this (02).
01
02
Fig. 1 Water tank 5l (1.3gal), 5m (16ft) delivery.
01
02
Fig. 2 Water tank 23l (6gal), 5m (16ft) or 11m (36ft) delivery.
01
02
Fig. 3 Water tank 23l (6gal), 30m (98ft) delivery.
Take the plug out of the tank, along with any pumps
and level gauges. Remove the tank from the metal
cage.
6.1.2 Choose the power supply line
Depending on the version, the device can be
provided with different power supply voltages. Their
value is shown on the product identification label.
Always make the electrical connections
with the power supply disconnected and
the circuit-breaker open.
When commencing installation make sure
that the specifications for the power supply
for the installation correspond with those
required by the device.
Make sure that the power source and
connecting cables are suitable for the
power consumption of the system.
