16
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 5002 5202 5402 5602
Interface 5004 5204 5404 5604
product temperature 5006 5206 5406 5606
interface temperature 5008 5208 5408 5608
average temperature 5010 5210 5410 5610
status 5012 5212 5412 5612
Span 5014 5214 5414 5614
temperature 1 5016 5216 5416 5616
temperature 2 5018 5218 5418 5618
temperature 3 5020 5220 5420 5620
temperature 4 5022 5222 5422 5622
temperature 5 5024 5224 5424 5624
max temperature 5026 5226 5426 5626
temperature sensor 1 location
(closest to bottom) 5028 5228 5428 5628
temperature sensor 2 location 5030 5230 5430 5630
temperature sensor 3 5032 5232 5432 5632
temperature sensor 4 location 5034 5234 5434 5634
temperature sensor 5 location
(closest to top) 5036 5236 5436 5636
Software version 5098 5298 5498 5698
Enron Modbus, Long, 32 bit, 32 bits of data per register, 1 register needed to get value
English Units, inches and degrees F
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 5102 5302 5502 5702
Interface 5104 5304 5504 5704
product temperature 5106 5306 5506 5706
interface temperature 5108 5308 5508 5708
average temperature 5110 5310 5510 5710
status 5112 5312 5512 5712
Span 5114 5314 5514 5714
temperature 1 5116 5316 5516 5716
temperature 2 5118 5318 5518 5718
temperature 3 5120 5320 5520 5720
temperature 4 5122 5322 5522 5722
temperature 5 5124 5324 5524 5724
max temperature 5126 5326 5526 5726
temperature sensor 1 location
(closest to bottom) 5128 5328 5528 5728
temperature sensor 2 location 5130 5330 5530 5730
temperature sensor 3 5132 5332 5532 5732
temperature sensor 4 location 5134 5334 5534 5734
temperature sensor 5 location
(closest to top) 5136 5336 5536 5736
Software version 5198 5398 5598 5798
Enron Modbus, Long, 32 bit, 32 bits of data per register, 1 register needed to get value
Metric Units, centimeters and degrees C
