AMETEK 7230 HT Digital Probe - Manual (Page 17)

15
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 31003 31203 31403 31603
Interface 31005 31205 31405 31605
product temperature 31007 31207 31407 31607
interface temperature 31009 31209 31409 31609
average temperature 31011 31211 31411 31611
status 31013 31213 31413 31613
Span 31015 31215 31415 31615
temperature 1 31017 31217 31417 31617
temperature 2 31019 31219 31419 31619
temperature 3 31021 31221 31421 31621
temperature 4 31023 31223 31423 31623
temperature 5 31025 31225 31425 31625
max temperature 31027 31227 31427 31627
temperature sensor 1 location
(closest to bottom) 31029 31229 31429 31629
temperature sensor 2 location 31031 31231 31431 31631
temperature sensor 3 31033 31233 31433 31633
temperature sensor 4 location 31035 31235 31435 31635
temperature sensor 5 location
(closest to top) 31037 31237 31437 31637
Software version 31099 31299 31499 31699
Long, 32 bit, 16 bits of data per register, 2 registers needed to get value
English Units, inches and degrees F
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 31103 31303 31503 31703
Interface 31105 31305 31505 31705
product temperature 31107 31307 31507 31707
interface temperature 31109 31309 31509 31709
average temperature 31111 31311 31511 31711
status 31113 31313 31513 31713
Span 31115 31315 31515 31715
temperature 1 31117 31317 31517 31717
temperature 2 31119 31319 31519 31719
temperature 3 31121 31321 31521 31721
temperature 4 31123 31323 31523 31723
temperature 5 31125 31325 31525 31725
max temperature 31127 31327 31527 31727
temperature sensor 1 location
(closest to bottom) 31129 31329 31529 31729
temperature sensor 2 location 31131 31331 31531 31731
temperature sensor 3 31133 31333 31533 31733
temperature sensor 4 location 31135 31335 31535 31735
temperature sensor 5 location
(closest to top) 31137 31337 31537 31737
Software version 31199 31399 31599 31799
Long, 32 bit, 16 bits of data per register, 2 registers needed to get value
Metric Units, centimeters and degrees C
