AMETEK 7230 HT Digital Probe - Manual (Page 15)

13
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 30303 30503 30703 30903
Interface 30305 30505 30705 30905
product temperature 30307 30507 30707 30907
interface temperature 30309 30509 30709 30909
average temperature 30311 30511 30711 30911
status 30313 30513 30713 30913
Span 30315 30515 30715 30915
temperature 1 30317 30517 30717 30917
temperature 2 30319 30519 30719 30919
temperature 3 30321 30521 30721 30921
temperature 4 30323 30523 30723 30923
temperature 5 30325 30525 30725 30925
max temperature 30327 30527 30727 30927
temperature sensor 1 location
(closest to bottom) 30329 30529 30729 30929
temperature sensor 2 location 30331 30531 30731 30931
temperature sensor 3 30333 30533 30733 30933
temperature sensor 4 location 30335 30535 30735 30935
temperature sensor 5 location
(closest to top) 30337 30537 30737 30937
Software version 30399 30599 30799 30999
Floating Point, 32 bit, 16 bits of data per register, 2 registers
needed to get value Metric Units, centimeters and degrees C
Data Big Endian/
HWHB/
1234
Little Endian/
Byte Swapped/
LWHB/3412
Big Endian/
Byte Swapped/
HWLB/2143
Little Endian/
LWHB/4321
Product 7002 7202 7402 7602
Interface 7004 7204 7404 7604
product temperature 7006 7206 7406 7606
interface temperature 7008 7208 7408 7608
average temperature 7010 7210 7410 7610
status 7012 7212 7412 7612
Span 7014 7214 7414 7614
temperature 1 7016 7216 7416 7616
temperature 2 7018 7218 7418 7618
temperature 3 7020 7220 7420 7620
temperature 4 7022 7222 7422 7622
temperature 5 7024 7224 7424 7624
max temperature 7026 7226 7426 7626
temperature sensor 1 location
(closest to bottom) 7028 7228 7428 7628
temperature sensor 2 location 7030 7230 7430 7630
temperature sensor 3 7032 7232 7432 7632
temperature sensor 4 location 7034 7234 7434 7634
temperature sensor 5 location
(closest to top) 7036 7236 7436 7636
Software version 7098 7298 7498 7698
Enron Modbus, Floating Point, 32 bit, 32 bits of data per register, 1
register needed to get value English Units, inches and degrees F
