14
COMMUNICATIONS REGISTER (40026) AND COILS 1-8 TABLE (continued)
Mode Parity Baud
Coil 8
B7 *
Coil 7
B6
Coil 6
B5
Coil 5
B4
Coil 4
B3
Coil 3
B2
Coil 2
B1
Coil 1
B0
Coil 8 =0
HEX
Coil 8 =1
HEX
ASCII 7N2 300 0 / 1 1 0 0 0 0 0 0 <40>
ASCII 7N2 600 0 / 1 1 0 0 0 0 0 1 <41>
ASCII 7N2 1200 0 / 1 1 0 0 0 0 1 0 <42>
ASCII 7N2 2400 0 / 1 1 0 0 0 0 1 1 <43>
ASCII 7N2 4800 0 / 1 1 0 0 0 1 0 0 <44>
ASCII 7N2 9600 0 / 1 1 0 0 0 1 0 1 <45>
ASCII 7N2 19200 0 / 1 1 0 0 0 1 1 0 <46>
ASCII 7N2 38400 0 / 1 1 0 0 0 1 1 1 <47>
ASCII 7E1 300 0 / 1 1 0 0 1 0 0 0 <48>
ASCII 7E1 600 0 / 1 1 0 0 1 0 0 1 <49>
ASCII 7E1 1200 0 / 1 1 0 0 1 0 1 0 <4A>
ASCII 7E1 2400 0 / 1 1 0 0 1 0 1 1 <4B>
ASCII 7E1 4800 0 / 1 1 0 0 1 1 0 0 <4C>
ASCII 7E1 9600 0 / 1 1 0 0 1 1 0 1 <4D>
ASCII 7E1 19200 0 / 1 1 0 0 1 1 1 0 <4E>
ASCII 7E1 38400 0 / 1 1 0 0 1 1 1 1 <4F>
ASCII 7O1 300 0 / 1 1 0 1 1 0 0 0 <58>
ASCII 7O1 600 0 / 1 1 0 1 1 0 0 1 <59>
ASCII 7O1 1200 0 / 1 1 0 1 1 0 1 0 <5A>
ASCII 7O1 2400 0 / 1 1 0 1 1 0 1 1 <5B>
ASCII 7O1 4800 0 / 1 1 0 1 1 1 0 0 <5C>
ASCII 7O1 9600 0 / 1 1 0 1 1 1 0 1 <5D>
ASCII 7O1 19200 0 / 1 1 0 1 1 1 1 0 <5E>
ASCII 7O1 38400 0 / 1 1 0 1 1 1 1 1 <5F>
ASCII 8N1 300 0 / 1 1 1 0 0 0 0 0 <60>
ASCII 8N1 600 0 / 1 1 1 0 0 0 0 1 <61>
ASCII 8N1 1200 0 / 1 1 1 0 0 0 1 0 <62>
ASCII 8N1 2400 0 / 1 1 1 0 0 0 1 1 <63>
ASCII 8N1 4800 0 / 1 1 1 0 0 1 0 0 <64>
ASCII 8N1 9600 0 / 1 1 1 0 0 1 0 1 <65>
ASCII 8N1 19200 0 / 1 1 1 0 0 1 1 0 <66>
ASCII 8N1 38400 0 / 1 1 1 0 0 1 1 1 <67>
ASCII 8E1 300 0 / 1 1 1 0 1 0 0 0 <68>
ASCII 8E1 600 0 / 1 1 1 0 1 0 0 1 <69>
ASCII 8E1 1200 0 / 1 1 1 0 1 0 1 0 <6A>
ASCII 8E1 2400 0 / 1 1 1 0 1 0 1 1 <6B>
ASCII 8E1 4800 0 / 1 1 1 0 1 1 0 0 <6C>
ASCII 8E1 9600 0 / 1 1 1 0 1 1 0 1 <6D>
ASCII 8E1 19200 0 / 1 1 1 0 1 1 1 0 <6E>
ASCII 8E1 38400 0 / 1 1 1 0 1 1 1 1 <6F>
ASCII 8O1 300 0 / 1 1 1 1 1 0 0 0 <78>
ASCII 8O1 600 0 / 1 1 1 1 1 0 0 1 <79>
ASCII 8O1 1200 0 / 1 1 1 1 1 0 1 0 <7A>
ASCII 8O1 2400 0 / 1 1 1 1 1 0 1 1 <7B>
ASCII 8O1 4800 0 / 1 1 1 1 1 1 0 0 <7C>
ASCII 8O1 9600 0 / 1 1 1 1 1 1 0 1 <7D>
ASCII 8O1 19200 0 / 1 1 1 1 1 1 1 0 <7E>
ASCII 8O1 38400 0 / 1 1 1 1 1 1 1 1 <7F>
* When reading register 40026, B7 will be a 0. When writing (changing ITMS communications to the new setting), change B7 to a 1.
