HighPoint RocketRAID 3510 User Manual
Page 13
RocketRAID 3xxx Hardware Description/Installation
For more information about LED support, contact our Customer Support Department.
BEEP1 – Speaker
Alarm (speaker): the speaker emits and audible alarm in the case of disk/array failure.
CONN10 (BBU)
Connector for battery backup (optional part).
2 - RocketRAID 3510 Adapter Layout
2-2
