19
The second METER screen shows the accumulated amp hours
and kilowatt hours for each shunt. Press the soft
key to view the next METER screen.
This screen shows the number of removed amp hours and
watt hours as measured by SHUNT A. Press the
soft key to view the SHUNT A charged screen.
The fourth meter screen displays the number of charged amp
hours and watt hours as measured by SHUNT A. Press the
soft key to view the fi rst SHUNT B METER screen.
Pressing the soft key brings up the SHUNT B
charged screen.
Pressing the soft key brings up the fi rst SHUNT C
METER screen.
METER/DC/SHUNT B
charged
AH 0kWH
DOWN UP TOP
METER/DC/SHUNT B
removed
AH 0kWH
DOWN UP TOP
METER/DC/SHUNT A
charged
12AH 0.160kWH
DOWN UP TOP
METER/DC/SHUNT A
removed
12AH 0.030kWH
DOWN UP TOP
A: -1AH 0.100kWH
B: 0AH 0.000kWH
C: 0AH 0.O00kWH
DOWN UP TOP
The fi rst METER screen shows the amount of instantaneous
current running through each shunt. A positive value
indicates current fl ow into the battery; a negative value
means a load is being supplied. Press the soft key
to view the AH and kWH (amp hour and watt hour) screen.
A: 0.1A 0.000 kW
B: 0.0A 0.000 kW
C: 0.0A 0.000 kW
DOWN STATUS
