STEP 8 - VERIFY PUSH BUTTON START SYSTEM OPERATION:
1. Ensure the FOB is located within the docking station.
2. Pressing the push button switch for one half second or pressing and holding will advance to the next mode every 0.5 seconds. All push-button presses will trigger the push button
switch to blink and cause the system to advance to the next state.
a. From OFF state: This will advance unit to ACC mode. The push-button will blink slowly.
b. From ACC mode: This will advance unit to IGN mode. The push-button will blink quickly indicating that the starter motor has not yet engaged.
c. From IGN mode: This will advance unit to CRANK mode for as long as button is pressed. Unit will go back to IGN mode when released. The push-button will stay illuminated,
indicating starter motor has been engaged.
d. From IGN mode: After a CRANK has been initiated this will advance unit to OFF state and push-button will no longer be illuminated and the sequence may be repeated.
e. From OFF state: Holding continuously will advance through to CRANK.
3. Pressing the push button for less than one half second prior to an engine CRANK will bring unit to OFF state.
STEP 9 - FOB PROGRAMMING
1. Locate a programmed FOB in the docking station. Activate the ACC mode and then Switch OFF within 20 seconds.
a. If the FOB is removed from the docking station before ACC is switched OFF then programming mode will not be entered.
b. Programming mode is identified by the Blue indicator flashing once per second.
c. Programming mode will extinguish in 30 seconds if left unattended.
2. Within 30 seconds, remove the programmed FOB from the docking station and install the FOB to be learned.
3. Press and release the Start/Stop switch (<1 sec). A valid read is identified by a steady blue indicator after which system operation transfers to ACC mode (i.e. “Ignition Switch
Sequence”).
4. Additional FOBs are added by repeating step 1 and 2.
5. A maximum of four FOBs can be stored in the system.
STEP 10 - FOB REMOVAL
1. Locate a programmed FOB in the docking station. Activate the ACC mode and then Switch OFF within 20 seconds.
a. If the FOB is removed from the docking station before ACC is switched OFF then programming mode will not be entered.
b. Programming mode is identified by the Blue indicator flashing once per second.
c. Programming mode will extinguish in 30 seconds if left unattended.
2. Press and hold the Start/Stop switch for >30 sec. After 30 seconds has expired, a steady blue indicator will indicate that all FOBs have been removed except the one used to
initiate programming mode.
