12-16 Volts
12-16 Volts
Ground
Tach Input from Ignition
BurnOut
Pit Road
Tranz Brake
Line Lock Button
S
Line Lock Solenoid
S
Tranz Brake Solenoid
12-16 Volts
Tranz Brake Button
12-16 Volts
Standards, Lencos, etc.
Fuse
7 Amp
Fourth Shift Output
Third Shift Output
Second Shift Output
First Shift Output
12-16 Volts
Inpu
t
Fuse
10 Amp
Figure #3
Shift Lights and Air Shifters
Suggested Wiring for Terminal Blocks
Output toShift Lights and
Air Shifters
Shift Lights and Air Shifters
Tie the outputs together for only the
number of shifts required.
Clutch Pedal or Linelock Switch *
*See Page #4
12 Volts
(Only used with CHEETAH Electronic Valve Bodies)
If high current relay needed (example,
Dedenbear and Biondo Electric Shifts)
see Fig.#4, page #7.
1
3
4
5
6
2
5
3
2
1
4
NOTE: Air/C02/Electric Shifters
Be sure to Set Relay #5 to 0.2 at position #14.
9/19/14
No Switch inbetween!
