Turn Function Switch knob clockwise until the right
LED display position reads 2. This position sets the
Race Second Shift RPM to within 100 RPM Fig. #4.
Factory Default = 9990 RPM (Fig. #4)
Program Position #2:
Do the same as Position #1.
Turn Function Switch knob clockwise until the right
LED display position reads 3. This position sets the
Race Third Shift RPM to within 100 RPM Fig. #5.
Factory Default = 9990 RPM (Fig. #5)
Program Position #3:
Do the same as Position #1.
Turn Function Switch knob clockwise until the right
LED display position reads 4. This position sets the
Race Fourth Shift RPM to within 100 RPM Fig. #6.
Factory Default = 9990 RPM (Fig. #6)
Program Position #4:
Do the same as Position #1.
Turn Function Switch knob clockwise until the right
LED display position reads 5. This position sets the
Race/BurnOut FallBack RPM, which is the RPM that
the controller resets on engine deacceleration Fig. #7.
Factory Default = 3000 RPM (Fig. #7)
We suggest not changing this setting till you try
in vehicle.*All RPM’s position 1,2,3,4,6,7,8 & 9
must be higher than this RPM or display will
read “NO”. If this happens change position in
error. Shut power off to Controller, then back on.
Program Position #5:
Do the same as Position #1.
9 9 9 2
10K 1K 100 POS. POS.
Fig. #4
9 9 9 3
10K 1K 100 POS. POS.
Fig. #5
5000 RPM
9 9 9 4
10K 1K 100 POS. POS.
Fig. #6
5500 RPM
3 0 0 5
10K 1K 100 POS. POS.
Fig. #7
3000 RPM
POSITION #4: Race Fourth (4-5) Shift RPM
POSITION #3: Race Third (3-4) Shift RPM
POSITION #2: Race Second (2-3) Shift RPM
POSITION #5: Race/BurnOut FallBack Shift RPM
