10
Turn Function Switch knob clockwise one increment, until
the right LED position display reads 1. This position sets the
Race First Shift RPM to within 100 RPM Fig. #1.
Note: This
shift needs to be 200-300 RPM early on 3, 4 and 5 speed transmissions.
Factory Default = 9990 RPM (Fig. #1).
Program Position #1:
a. Push Reset Button: Display will read position
number only.
b. To set 1000 RPM’s:
Push 1000’s Button till it reads
1-15 (1000-15000 RPM).
EXAMPLE: If you stop at the #6, it will read as shown
in Fig. #2.
c. To set 100 RPM’s:
Push 100’s Button till it reads
0-9 (000-900 RPM).
EXAMPLE: If you stop at the #7, it will read as shown
in Fig. #3.
POSITION #1: Race First (1-2) Shift RPM
Race Mode -
Burn Out Mode -
Pit Road Mode -
Hold Mode -
CHEETAH E-SHIFT Controller
Programming for 4 Shifts
Your unit has been shipped with specific factory defaults which are changeable by you.
Programming Function Switch Positions 1 -15:
Turn power on to your CHEETAH E-SHIFT Controller, but do not start engine.
POSITION #0: Normal Running
Display reads Engine RPM
Display reads Burn
Display reads P._rd
Display reads Hold
9 9 9 1
10K 1K 100 POSITION
Fig. #1
6 0 0 1
10K 1K 100 POS. POS.
Fig. #2
6000 RPM
6 7 0 1
10K 1K 100 POS. POS.
Fig. #3
6700 RPM
